-Description of BT-1500 Round Table Cutting and Milling Machine
BT-1500 Round Table Cutting and Milling Machine.This machine is major in circular forming the circular slabs, which is the first choice euqipment for processing circular tables and other crafts, Siamese-style shape, simple, beautiful. The wheels are driven by main motor,with electric lift, and can manually adjust fine-tuning process diameter; The workflat with electric rotary, is driven by the independent reducer of the base and main motor. It is very steady and durable, which can order different processing sizes as the customers' request.
-Parameter of BT-1500 Round Table Cutting and Milling Machine
No. | Name | Parameter |
1 | Nos. Of cutting head | 1pc |
2 | Diameter Of Cutting Blade | Φ130-150mm *20mm |
3 | Main motor power | 3kw |
4 | Speed of conveyor | 1.5m/min |
5 | Max. Cutting width | 1500mm |
6 | Max. Cutting thickness | 10-20mm |
7 | Total power | 13kw |
8 | Size of machine | 2.8*2.1*2m |
9 | Weight | 1500kg |
10 | Water consumption | 100L/min |
-Product Description
Foshan Bao Tao machinery Equipment Co., Ltd. is a well-known brand manufacturer of various kinds of ceramics, stone, glass, deep processing machinery and equipment.
The main products are: arc machine polishing machine, stone line polishing machine, multi-function polishing machine, plane polishing machine, intelligent water knife, edge grinding machine, CNC automatic cutting machine, automatic dry cutting line and other various ceramic processing equipment.
