Functions:
Profiling, grinding, 45 degree making, notching grooves.
Features and advantages:
Compact size, Electrical side bar, fully automatic, Multi head profiling and polishing wheels
Tools and consumable parts:
Diamond metal bond grinding cup wheels,
Diamond rounding profiling wheels,
Resin polishing wheels,
Grooving notching disc.
Technical parameters:
Processing width | mm | Max 1200 |
Processing thickness | mm | max 20 |
Conveyor belt width | mm | 300 |
Processing speed | m/min | 1-4 |
Total power | kw | 20 |
Power condition | 380V 3PH 50HZ | |
Dimension(L*W*H) | meter | 3.5*1.8*1.8 |
Weight | kg | 1600 |
